Home Power & Sail Vertical rope/chain windlasses RC6
VWC 1000
Back to products
RC12HD

RC6

12V  24V

Description

Suitable for 6mm (1/4″) chain and 12mm (1/2″) 8-plait nylon rope, the RC6 automatic rope/chain anchor winch is Maxwell’s smallest windlass in the vertical RC series and is most commonly used on boats ranging from 4.5-7.5m (15-25′). With more than 12,000 in global circulation, the RC6 has risen to become one of the most popular windlasses in the RC range.

  • The RC6 features Maxwell’s patented Wave Design™ chainwheel. Refer below for more information about this innovative feature.
  • Providing most of the features of the larger RC8, the RC6 has been designed with the smaller, trailer boat market in mind.
  • The in-line, vertical gearbox and motor means quick and easy installation by either the boat yard or the DIY aftermarket customer.
  • An inexpensive, high performance and great looking windlass; the RC6 is built for durability and years of trouble-free use.
  •  The RC6 is a Low-Profile unit meaning there is no optional capstan drum. If a capstan is needed in addition to the rope/chain gypsy, then a step up to the RC8-6 would be the next option to consider.
Specifications

Specifications

Specifications
ModelRC6
Maximum Pull/Lift350 kg (770 lbs)
Static Hold700 kg (1540 lbs)
Chain Short Link6 mm / 7 mm (1/4”)
Rope Size (Nylon)
(8 plait recommended)
12 mm (1/2”)
Chain Speed (Anchor Retrieval)24 m/min (79 ft/min)
Rope Speed (Anchor Retrieval)21 m/min (69 ft/min)
Power Supply (DC)12V, 24V
Motor Power (Watt)500
Net Weight8.5 kg (18.7 lbs)
Resources

Resources

Owner’s Manual

CAD Files

CAD Files

3D CAD Files
